20m Long Reach Boom for K-Omatsu PC350 Excavator

Rincian produk

Sertifikasi: CE, ISO9001: 2000, SGS

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1

Harga: 19800

Dapatkan Harga Terbaik

Hubungi Sekarang

Spesifikasi

Deskripsi

Spesifikasi

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            20m excavator long reach boom, K-Omatsu PC350 excavator arm, long arm excavator with warranty


Nomor Model.:	HD-LDB350	Kapasitas ember:	0,5m3
Bahan:	Q345b (Sgc490)	Panjang boom:	11000mm
Panjang lengan:	9000mm	Kedalaman penggalian maks:	14500mm
Cakupan maksimal yang luas:	19600mm	Tinggi Penggalian Maks:	14920mm
Tinggi Lipat:	3210MM	Setelan Tonase Ekskavator:	35ton
Total panjang:	20000mm	Berat:	6000kg
Penularan:	Transmisi hidrolik	Jenis drive:	Penggerak pembakaran internal
Silinder ember:	1

Nomor Model.:	HD-LDB350
Kapasitas ember:	0,5m3
Bahan:	Q345b (Sgc490)
Panjang boom:	11000mm
Panjang lengan:	9000mm
Kedalaman penggalian maks:	14500mm
Cakupan maksimal yang luas:	19600mm
Tinggi Penggalian Maks:	14920mm
Tinggi Lipat:	3210MM
Setelan Tonase Ekskavator:	35ton
Total panjang:	20000mm
Berat:	6000kg
Penularan:	Transmisi hidrolik
Jenis drive:	Penggerak pembakaran internal
Silinder ember:	1

Deskripsi

20m Long Reach Boom for K-Omatsu PC350 Excavator

Key Specifications

Material: Q345B (SGC490)
Total Length: 20000mm (Boom: 11000mm, Arm: 9000mm)
Max Dig Depth: 14500mm
Max Extensive Scope: 19600mm
Max Dig Height: 14920mm
Folding Height: 3210mm
Bucket Capacity: 0.5m³
Suitable for: 35Ton Excavators
Warranty: 6 months
Color: Optional
CE Certification Available

Included Components

Hydraulic pipe and Lubricant pipe System
1 × Bucket (0.5m³)
1 × Counter Weight (3ton)
1 × Bucket Cylinder
1 × Connect Rod
4 × High-pressure Hose
6 × Pins
Several Shims
Installation Tools

Additional arm cylinder and counter weight available upon request. We offer complete customization services for long booms to meet your specific requirements.

Product Features

Maintains original excavator performance
Constructed from high-strength steel plate
Significantly improves operational scope
Compatible with various excavator makes and models
Multiple material options available (Q345B, Q690D, Weldox)

Model Specifications

Model	LDB120	LDB200-1	LDB200-2	LDB300	LDB350-1	LDB350-2	LDB450
Boom Length (mm)	7100	8220	10000	10000	11000	12000	13000
Arm Length (mm)	5900	7160	8000	8000	9000	10000	11000
Weight (kg)	3000	4000	4200	5200	6000	6500	7000
Max Dig Depth (mm)	9000	11340	12200	12200	14500	16100	18000
Max Extensive Scope (mm)	12500	15100	17600	17600	19600	21600	23600
Max Dig Height (mm)	11300	12510	13500	13720	14920	16100	17300
Folding Height (mm)	2900	2980	3040	3210	3210	3400	3400
Bucket Capacity (m³)	0.3	0.5	0.4	0.4	0.5	0.6	0.6
Suit Excavator Tonnage (ton)	12	20	20	30	35	35	45
